Home/Products/Air vac 100 cfm wet dry vac only
SPAV100SS/VO

Air vac 100 cfm wet dry vac only

ATEX certifiedExplosion proofAir operatedWet & dryStainless steel
Request a quote on this unit →

Spill control air vacuum. 100 cfm. 100 psi. Twin venturi's. Vacuum only Wet and Dry.

SCAV-logo

SPAV top 800w

  • 1 - The pneumatic power head is silencer with a mild steel shroud. The internal silencing baffles mean the sound signature is very low and does not affect perfomance of the single or twin venturi's.
  • 2 - This model has a stainless steel tank which is useful in many industries, including the food industry.
  • 3 - Each unit is supplied with anti-static explosion proof suction hose.
  • 4 - The floor tool is a 450mm wide squeegee.
  • 5 - The wand is chromed steel two piece 38mm.
  • 6 - The tank has a tipping facility and also a grounding chain.
  • 7 -The unit picture can be configured both wet and dry.

The pneumatic air powered vacuum head is attached by stainless steel bolts to a powder coated mild steel plate which attaches to the stainlaess steel tank.

 Explosion-proof-vacuum-with-numbersSPAV-explosion-proof-vacuum-pneumatic-power-head100-cfm-main-features-vac-only

Spill Air vacuum for spill control - wet and dry 60/70 litre stainless steel tank. Vacuum only.

WaterMudCoolantSump oilBilgeChemicalsGeneral oilsContaminated waterDustsWood chipsMetal chipsNuts and boltsPlasticsMetalsGravelSoilSeedsGrainsGeneral dry factory waste
Not for flammable fluids or explosive dusts

This unit is not to be used for flammable fluids or explosive dusts. Models with EX in their code can be used for explosive dusts and flammable fluids.

The SPAV spill control air vacuum comes in 4 models. The low air 28 cfm model is for wet only and the 48 and 100 cfm models can do both wet and dry and the 180 cfm model is ultra high powered The twin venturis of the 48, 100 and 180  cfm models give this unit high power and high air flow in both wet and dry applications.

The stainless steel tank version of the SPAV100SS can be configured as an explosion proof model with anti-static hose, stainless tank and anti-static fittings making this unit ideal for fuels, oils, diesel and grains and explosive dust and flour.

SPAV-SS-tipping
  • 60/70 litre stainless steel tank
  • Vacuum only
  • Wet and dry
  • Tipping tan
Airflow100 CFM
Vacuum16″ Hg
Water lift229
Pressure100 psi
Hose size38 / 50 mm
PowerPneumatic

Maximum hose length

HoseWetDry
38 mm10 m15 m
50 mm7 m10 m
  • Each unit includes;

    • Silenced power head
    • Vacuum ball valve
    • 1/2" Chicago claw coupling
    • 38mm chrome wand
    • 38mmx450mm squeegee head
    • 3 metres 38mm vac hose
    • 38mm x450mm floor vac brush
    • 38mm crevice tool
    • 38mm round dusting brush
    • Dry cloth filter bag & cage
    • Drain hose and valve

Air operated vacuums with no electrical components suitable for all explosion risk areas including Zones 1 and 2 (Gas) and 21 and 22 (Dust). ( please note this unit is not explosion proof. All mdels with EX after their model numebr are explosion proof).

SCAV-3-image-box
Standard accessories
Standard accessories

Specifications

ModelSPAV100SS/VO
SKUSPAV100SS/VO
