Spillmaster Reverse 20 cfm 110 litres
Vacuum air powered pneumatic hopper. Spillmaster 20 cfm reverse pump out fluid vacuum.
Please Note: This unit is designed to vacuum fluids from containers not spills on the ground. For spills on the ground you need higher air flow. Please choose 28 cfm models or above. Click the upgrade box for the 28 cfm model.
| This unit is fitted with | Tank size 110 litres |
Each unit is custom built to order. Build time 21-28 days.
The Spillmaster vacuum system is manufactured in Australia from mild powder coated steel. These units are tough and powerful. Powered by the Spillrite venturi system they come in 8 main power configurations using two styles of venturis.
|
 |
|
|
The Spillmaster Hi Flow venturi system is designed primarily for dry waste but can do wet as well. With the high flow venturis this style of venturi enables the unit to be effective with all types of dry waste. Each unit comes standard with a float vale system for when wet vacuuming is required. When fitted with this style of venturi they can be configured as follows; 1. 60 cfm - 60 litre tank, 110 litre tank, 200 litre tank - Hi air Flow venturi - Single venturi 2. 120 cfm - 60 litre tank, 110 litre tank, 200 litre tank - Hi air Flow venturis - Double venturis 3. 200 cfm - 60 litre tank, 110 litre tank, 200 litre tank - Hi air Flow venturis - Triple venturis |
The Spillmaster Reverse venturi system is designed primarily for wet but can do dry. If you do not want long hose lengths and your dry waste is light and you want the reverse pump out capability then this would be the system to choose. When fitted with this style of venturi they can be configured as follows; 4. 20 cfm - 60 litre tank, 110 litre tank, 200 litre tank - reverse fluid pump out single venturi 5. 28 cfm - 60 litre tank, 110 litre tank, 200 litre tank - reverse fluid pump out single venturi 6. 48 cfm - 60 litre tank, 110 litre tank, 200 litre tank - reverse fluid pump out twin venturi 7. 100 cfm - 60 litre tank, 110 litre tank, 200 litre tank - reverse fluid pump out twin venturi 8. 180 cfm - 60 litre tank, 110 litre tank, 200 litre tank - reverse fluid pump out twin venturi |
The units are manufactured from 3mm mild steel with 2mm mild steel silencer and venturi protector. High quality air connections and a quality finish, the Spillmaster range can be configured for many wet and dry applications including;
- reverse pump out
- explosion proof
- rapid fluid recovery
- fast dry waste recovery
|
|
Each unit includes;
|
|
|
Large pump up tyres and strong steel frame makes the Spillmaster a perfect factory, oil rig, fuel depot spill control vacuum system. |
|
|
Triple, double or single venturi configurations for high power and low air usage. Each Spillmaster unit is manufactured from powder coated mild steel. |
|
|
Large front wast trap with ball valve. Ideal for dry waste and also reverse pump out for fluid. |
 |
The 20 cfm reverse pump out unit uses Nitto connections for vacuum and reverse. |
| Please note these units are built to order and generally take 3-4 weeks to complete. |
Specifications
| Model | Spillmaster 20/110 litre vac |
| SKU | SPMR20/110 |
